AF Fingerprint Proof Glass Panel

AF anti-fingerprint glass:

It is to coat the outer surface of the glass with a layer of nanomaterials to minimize the surface tension of the glass, reduce the contact area between dust and water vapor and the glass when human touch the surface of the panel, so that the surface of the panel has a strong resistance to fingerprint, water vapor and oil pollution, so that the glass panel for a long time to keep clean and clean.

AF anti - fingerprint is formed by the vacuum coating machine AF liquid plating on the glass surface.

AF anti - fingerprint parameters: drop Angle and eraser and steel velvet to detect AF liquid adhesion in the glass panel.

AF anti-fingerprint features: waterproof, anti-fingerprint, anti-oil, wear-resistant and so on.

AF anti-fingerprint glass thickness: 1.1mm, 2mm, 3mm, 4mm, 5mm and so on.

Product Specification
Mode! Number	AF Glass
material	CSG、panda、AGC、Corning、NEG、XFX
Transmittance	≥ 89%
AF initial water drop angle	105-110°
abrasion resistant	Load 1000g; 0000 # steel velvet! Friction speed: contact area 20mm * 20mm, friction times 1500 times
Water droplet angle after AF wear resistance	≤ 0.05
Thickness	1.1mm 2mm 3mm 4mm 5mm 6mm
Thickness tolerance	±0.2mm
Mos hardness	6H
Display glass specifications	Customized according to customer design drawings
Application	instrumentation, display protection screen, touch screen and so on
Hardware customization	Color, size, thickness, AF/AR/AG,2.5D,3D,Profiled/perforated

Product Application

application scenarios of af glass

AF anti-fouling and anti-fingerprint glass is widely used in mobile phones, computer display protection screen, instruments, touch screens, outdoor displays and so on.
